FLOAT SWITCH / BLOWER
® ® ®

MARINE RULE-A-MATIC FLOAT SWITCH 12/24/32 VDC

PUMPS MODEL: 35A / 35FA

⦁ Dimensions: 127mm long, 40mm wide, 110mm high
(at max. lift)
⦁ Maximum Current: 14(amps)
⦁ For automatic on/off bilge pump control.
⦁ Switch design prevents rapid on/off cycling.
⦁ Also available with fuse holder - see below
35A / 35FA
⦁ Mercury Free
⦁ Packaged Dimensions: L:14.00 x H:11.00 x W:14.00cm
⦁ Actual Weight: 0.10 Kg (Approx. 0.30 Kg packed)

RULE-A-MATIC® PLUS™ FLOAT SWITCH
12/24/32 VDC

MODEL: 40A / 40FA
⦁ Maximum Current: 20(amps)

40A / 40FA

RULE INLINE BLOWER 3" 12 V / 24 V
RULE INLINE BLOWER 4" 12 V / 24 V

Waterproof In-Line Blower
⦁ Efficient high-volume air flow
⦁ Quiet operation
⦁ Low amp draw
⦁ Slip-on inlet and outlet ducting connections
⦁ Sealed motor shaft for moisture protection
⦁ Corrosion resistant nickel-plated motor housing
⦁ IMCI (CE) certified
140/140-24 240/240-24
⦁ USCG 183.410 compliant for ignition protection

FLANGEMOUNT BLOWER 4" 12 V / 24 V
Ÿ Extended Life 5,000 Hour Motor
Ÿ Tough Reinforced Thermoset Plastic Housing
Ÿ Mounts to any flat surface
Ÿ Slip-On any Inlet Ducting Connection
Ÿ Efficient High Volume Air Flow
Ÿ Low Current Draw
Ÿ Corrosion-Resistant Material Throughout
Ÿ Meets USCG Electrical Regulations of Title 33
Ÿ Complies with ISO 9097 Marine
Ÿ CE Conforms with EN5008-1
35760-0092 12V 35760-0094 24V
